ASUS B9406CAA-TH1168X 14″ WQXGA Intel Ultra X7 358H 32GB LPDDR5X 1TB 2280 PCIe G5 WiFi 7 Touch Screen Gentle Grey WIN11 Pro(aipc) 3YR Onsite

ASUS B9406CAA-TH1168X 14″ WQXGA INTEL ULTRA X7 358H 32GB LPDDR5X 1TB 2280 PCIE G5 WIFI 7 TOUCH SCREEN GENTLE GREY WIN11 PRO(AIPC) 3YR ONSITE
Tech Specs:
Part No 90NX09J2-M01A10
Sales Model Name B9406CAA-TH1168X
EAN Code 4711636509022
UPC Code 199291509023
WEEE 0.603
BASE UNIT VSNX09J2-BU1000
Operating System Windows 11 Pro
Office 1-month trial for new Microsoft 365 customers. Credit card required.
LCD cover-material Mg-Al
LCD cover-color Jet Fog
Top case-material Mg-Al
Top case-color Jet Fog
Bottom case-material Mg-Al
Bottom case-color Jet Fog
Military grade US MIL STD 810H military grade standard (24 procedures)
Panel Size 14.0-inch
Backlit
OLED Tandem OLED
Brightness 600nits (1400nits HDR peak brightness)
Resolution WQXGA+ (2880 x 1800) 16:10
Glare Anti-glare display
Color gamut DCI-P3: 100%
View angle(H/V) 85/85
Response time(Typ/Max) (ms) 1/1
Refresh rate 120Hz
Contrast (Typ) 1000000:1
Touch Panel Touch screen with Corning® Gorilla® Glass Victus® and Corning® Gorilla™ Matte
Screen-to-body ratio 91 %
Pantone Pantone Validated
IPS-level
VESA CERTIFIED Display HDR VESA CERTIFIED Display HDR True Black 1000
Processor Intel® Core™ Ultra X7 Processor 358H 1.9 GHz (18MB Cache, up to 4.8 GHz, 16 Cores, 16 Threads)
Intel® AI Boost NPU up to 50 TOPS
Neural processor Intel® AI Boost NPU
Chipset N/A
Discrete/Share Share
Integrated GPU Intel® Arc™ Graphics(available for Intel® Core™ Ultra H 5/7/9 with dual channel memory)
VRAM N/A
How to upgrade memory Not Available
Expansion Slot(includes used) 1x M.2 2280 PCIe 4.0×4
On board memory 32GB LPDDR5X on board
DIMM Memory
Total System Memory LPDDR5X 32GB
Storage 1TB M.2 2280 NVMe™ PCIe® 5.0 SSD
Front-facing camera 1080p FHD camera (AI image upscaling up to 5MP) with IR function to support Windows Hello
With privacy shutter
Wireless
On board Wireless Wi-Fi 7(802.11be) (Triple band) 2*2 + Bluetooth® 6.0 Wireless Card
NumberPad N/A
FingerPrint FingerPrint
Keyboard type Backlit Chiclet Keyboard
Keyboard language English
I/O ports 2x USB 3.2 Gen 2 Type-A
2x Thunderbolt™ 4, compliant with USB4, support display / power delivery
1x HDMI 2.1 TMDS
1x 3.5mm Combo Audio Jack
Audio Dolby Atmos
6 built-in speakers
Built-in array microphone
Battery 70WHrs, 2S2P, 4-cell Li-ion
AC Adapter TYPE-C, 90W AC Adapter, Output: 20V DC, 4.5A, 90W, Input: 100~240V AC 50/60Hz universal (Adapter+power cord)
Required charging power Min: 80W
Max: 90W
*The indicated wattage is for demonstrating the system’s support capability as required by EU regulations. For optimal system performance, please use the standard-wattage adapter or higher.
Dimension (WxHxD) 31.09 x 21.28 x 1.09 ~ 1.64 cm (12.24″ x 8.38″ x 0.43″ ~ 0.65″)
Starting Weight (with Battery) 1.10 kg (2.43 lbs)
Starting Weight (w/o Battery) 0.85 kg (1.87 lbs)
Security Fingerprint sensor
IR webcam with Windows Hello support
Intel® Boot Guard
Trusted Platform Module (TPM) 2.0
Microsoft Secured-core PC
Support Absolute Persistence 2.0 (Computrace)
BIOS Self Recovery
BIOS Protection Support
Microsoft Pluton Security Processor
Intel CSME Firmware Resilience
Platform Firmware Resiliency Support
Microsoft Security Level 3
CSME BIOS Redundancy Assistance
Intel® BIOS Guard
ASUS ExpertGurdian with NIST SP 800 193 compliance
N/A
Antivirus N/A
MyASUS feature System diagnosis
Battery health charging
Fan Profile
Splendid
Tru2Life
Function key lock
WiFi SmartConnect
AppDeals
Link to MyASUS
MyExpert Features Chat
Knowledge Hub
Advanced Tool
ExpertMeet(All)
File Search
Built-in Apps MyASUS
ASUS MyExpert (Not supported in China, 16GB RAM or higher)
AI ExpertMeet (China only)
Disclaimer for Built-in Apps Built-in Apps vary from OS SKU.
*MyASUS/McAfee don’t support in Clean Build/without OS/G sku/Win SE/Windows on ARM/Linux OS (ex. Endless, Kylin, Ubuntu)
Included in the Box Sleeve
Reparability Index (for France) 09.9
Reparability Index (for Belgium) 09.1
Ecolabels & Compliances EPEAT Gold with Climate+
Energy star 9.0
FSC Mix
REACH
RoHS
TCO Certified
Base Warranty 3Y OnSite Service
