ASUS B5605CAA-T90094X 16″ WUXGA Intel U7 356H 32GB DDR5 512GB 2280 PCIe G4 WiFi 7 Touch Screen Gentle Grey WIN11 Pro(aipc) 3YR Onsite

ASUS B5605CAA-T90094X 16″ WUXGA INTEL U7 356H 32GB DDR5 512GB 2280 PCIE G4 WIFI 7 TOUCH SCREEN GENTLE GREY WIN11 PRO(AIPC) 3YR ONSITE
Tech Specs:
Part No 90NX09Z1-M00370
Sales Model Name B5605CAA-T90094X
EAN Code
UPC Code
WEEE
BASE UNIT VSNX09Z1-BU3019
Operating System Windows 11 Pro
Office 1-month trial for new Microsoft 365 customers. Credit card required.
LCD cover-material Aluminum
LCD cover-color Gentle Grey
Top case-material Aluminum
Top case-color Gentle Grey
Bottom case-material Aluminum
Bottom case-color Gentle Grey
Military grade US MIL STD 810H military grade standard (24 procedures)
Panel Size 16.0-inch
Backlit LED Backlit
OLED
Brightness 400nits
Resolution WUXGA (1920 x 1200) 16:10
Glare Anti-glare display
Color gamut sRGB: 100%
View angle(H/V) 178/178
Response time(Typ/Max) (ms) 20/25
Refresh rate 120Hz
Contrast (Typ) 1200:1
Touch Panel Touch screen
Screen-to-body ratio 85 %
Pantone
IPS-level Wide view
VESA CERTIFIED Display HDR
Processor Intel® Core™ Ultra 7 Processor 356H 1.9 GHz (18MB Cache, up to 4.7 GHz, 16 Cores, 16 Threads)
Intel® AI Boost NPU up to 50 TOPS
Neural processor Intel® AI Boost NPU
Chipset N/A
Discrete/Share Share
Integrated GPU Intel® Graphics
VRAM N/A
How to upgrade memory
Expansion Slot(includes used) 2x DDR5 SO-DIMM slots
1x M.2 2230 PCIe 4.0×4
1x M.2 2280 PCle 4.0/5.0×4
On board memory
DIMM Memory 32GB DDR5 SO-DIMM
Total System Memory DDR5 32GB
Storage 512GB M.2 2280 NVMe™ PCIe® 4.0 SSD
SSD Housing for storage expansion
Front-facing camera 5.0M camera with IR function to support Windows Hello
With privacy shutter
Wireless Wi-Fi 7(802.11be) (Triple band) 2*2 + Bluetooth® 6.0 Wireless Card
On board Wireless
NumberPad N/A
FingerPrint FingerPrint
Keyboard type Backlit Chiclet Keyboard
I/O ports 2x USB 3.2 Gen 1 Type-A
2x Thunderbolt™ 4, compliant with USB4, support display / power delivery
1x HDMI 2.1 TMDS
1x 3.5mm Combo Audio Jack
1x RJ45 Gigabit Ethernet
Micro SD card reader
Audio Audio by Dirac
Built-in speaker
Built-in array microphone
Battery 63WHrs, 3S1P, 3-cell Li-ion
AC Adapter TYPE-C, 65W AC Adapter, Output: 20V DC, 3.25A, 65W, Input: 100~240V AC 50/60Hz universal (Adapter+power cord)
Required charging power Min: 55W
Max: 65W
*The indicated wattage is for demonstrating the system’s support capability as required by EU regulations. For optimal system performance, please use the standard-wattage adapter or higher.
Dimension (WxHxD) 35.84 x 25.39 x 1.00 ~ 1.80 cm (14.11″ x 10.00″ x 0.39″ ~ 0.71″)
Weight (with Battery) 1.84 kg (4.06 lbs)
Weight (w/o Battery) 1.61 kg (3.55 lbs)
Security Fingerprint sensor integrated with Power Key
Kensington Nano Security Slot™(6x 2.5mm)
BIOS Booting User Password Protection
BIOS Integrity Measurement Support
BIOS Self Recovery
BIOS setup user password
CSME BIOS Redundancy Assistance
Enhanced Password Strength
HDD User Password Protection and Security
Intel CSME Firmware Resilience
Intel® BIOS Guard
Intel® Boot Guard
Microsoft Secured-core PC
Microsoft Security Level 3
Support Absolute Persistence 2.0 (Computrace)
Trusted Platform Module (TPM) 2.0
ASUS ExpertGurdian with NIST SP 800 155 compliance
ASUS ExpertGurdian with NIST SP 800 193 compliance
N/A
Antivirus N/A
MyASUS feature System diagnosis
Battery health charging
Fan Profile
Splendid
Tru2Life
Function key lock
WiFi SmartConnect
AppDeals
Link to MyASUS
MyExpert Features Chat
Knowledge Hub
Advanced Tool
ExpertMeet(All)
File Search
SafeGuard Backup(Dual SSD, additional purchase before shipment)
Built-in Apps AI ExpertMeet (AI features need devices with 12GB RAM or more)
MyASUS
Disclaimer for Built-in Apps Built-in Apps vary from OS SKU.
*MyASUS/McAfee don’t support in Pure OS/without OS/G sku/Win SE/Windows on ARM/Linux OS (ex. Endless, Kylin, Ubuntu)
Included in the Box
Reparability Index (for France) 9.9
Reparability Index (for Belgium) 9.5
Ecolabels & Compliances EPEAT Gold with Climate+
Energy star 9.0
FSC Recycled
REACH
RoHS
TCO Certified
Base Warranty 3Y OnSite Service
Recommended Warranty Packag
